Ventus Plenum Boxes
Air Distribution
Ventus plenum boxes are designed to guarantee a good distribution of air, prior to diffusion through the terminals through a tight horizontal or vertical air pattern even at low volumes. Their use consist of the supply and exhaust of conditioned air and they apply to any grille type and size.
Manufactured with 12mm black PVC foam board they are not prone to moisture, are lightweight, fire retardant and have excellent thermal and sound insulation properties.
Our company has the facilities and experience to accommodate plenum boxes with a high differentiation and customization degree.
The client has the choice of entry connection of the duct (back, side, top) and diameter. The shape of the duct can be rounded or oval as requested.
Suggested Dimensions
For the below-mentioned brands we suggest the following Plenum Box dimensions for your ease of use.
Brand | Model | kW | m3/h | BTU/h | Supply: (L) | (W) | (D) | Return: (L) | (W) | (D) |
---|---|---|---|---|---|---|---|---|---|---|
Daikin | FBA35A | 3.40 | 900 | 11,601 | 497 | 183 | 100 | 659 | 215 | 100 |
Daikin | FBA50A | 5.00 | 900 | 17,061 | 497 | 183 | 100 | 659 | 215 | 150 |
Daikin | FBA60A | 6.80 | 1,080 | 23,202 | 797 | 183 | 100 | 959 | 215 | 100 |
Daikin | FBA71A | 7.10 | 1,080 | 24,226 | 797 | 183 | 100 | 959 | 215 | 100 |
Daikin | FXSQ15 | 1.70 | 522 | 5,801 | 345 | 183 | 100 | 509 | 215 | 100 |
Daikin | FXSQ20 | 2.20 | 540 | 7,507 | 345 | 183 | 100 | 509 | 215 | 100 |
Daikin | FXSQ25 | 2.80 | 540 | 9,554 | 345 | 183 | 100 | 509 | 215 | 100 |
Daikin | FXSQ32 | 3.60 | 570 | 12,284 | 345 | 183 | 100 | 509 | 215 | 150 |
Daikin | FXSQ40 | 4.50 | 900 | 15,355 | 497 | 183 | 100 | 659 | 215 | 150 |
Daikin | FXSQ50 | 5.60 | 912 | 19,108 | 497 | 183 | 100 | 659 | 215 | 200 |
Daikin | FXSQ63 | 7.10 | 1,260 | 24,226 | 797 | 183 | 100 | 959 | 215 | 200 |
Toshiba Air Conditioning | MMD-AP0076BH-E | 2.20 | 540 | 7,507 | 645 | 185 | 100 | 665 | 240 | 100 |
Toshiba Air Conditioning | MMD-AP0096BH-E | 2.80 | 570 | 9,554 | 645 | 185 | 100 | 665 | 240 | 100 |
Toshiba Air Conditioning | MMD-AP0126BH-E | 3.60 | 570 | 12,284 | 645 | 185 | 150 | 665 | 240 | 150 |
Toshiba Air Conditioning | MMD-AP0156BH-E | 4.50 | 800 | 15,355 | 645 | 185 | 150 | 665 | 240 | 150 |
Toshiba Air Conditioning | MMD-AP0186BH-E | 5.60 | 800 | 19,108 | 645 | 185 | 200 | 665 | 240 | 200 |
Toshiba Air Conditioning | MMD-AP0246BH-E | 7.10 | 1,200 | 24,226 | 945 | 185 | 200 | 965 | 240 | 200 |
Toshiba Air Conditioning | RAV-RM561BTP-E | 5.00 | 800 | 17,061 | 645 | 185 | 200 | 665 | 240 | 200 |
Toshiba Air Conditioning | RAV-RM801BTP-E | 7.10 | 1,200 | 24,226 | 945 | 185 | 200 | 965 | 240 | 200 |
Gree | GUD-035-PS | 3.50 | 650 | 11,942 | 590 | 127 | 100 | 705 | 205 | 100 |
Gree | GUD-050-PS | 5.00 | 950 | 17,061 | 890 | 127 | 100 | 1,005 | 205 | 100 |
Gree | GUD-071-PS | 7.00 | 1,200 | 23,885 | 1,190 | 147 | 100 | 1,305 | 225 | 100 |
Gree | GUD-071-PS | 7.00 | 1,200 | 23,885 | 745 | 220 | 100 | 905 | 265 | 100 |
Gree | GUD-085-PS | 8.50 | 1,400 | 29,003 | 1,190 | 147 | 100 | 1,305 | 225 | 100 |
Gree | GUD-085-PS | 8.50 | 1,400 | 29,003 | 745 | 220 | 100 | 905 | 265 | 100 |
Haier | AD25S2SM2FA | 2.50 | 530 | 8,530 | 597 | 171 | 100 | 765 | 157 | 100 |
Haier | AD35S2SM3FA | 3.50 | 840 | 11,942 | 597 | 171 | 100 | 583 | 243 | 150 |
Haier | AD50S2SM3FA | 5.00 | 1,020 | 17,061 | 997 | 171 | 100 | 983 | 243 | 200 |
Haier | AD71S2SM3FA | 7.10 | 1,440 | 24,226 | 997 | 171 | 100 | 983 | 243 | 200 |
Inventor | V5MDI32-24WiFiR | 5.28 | 880 | 18,016 | 930 | 180 | 200 | 1,005 | 235 | 200 |
Inventor | V6MDI32-18WiFiR | 5.28 | 880 | 18,016 | 715 | 145 | 200 | 790 | 195 | 200 |
Inventor | V7MDI32-12WiFiR | 5.28 | 880 | 12,000 | 542 | 157 | 200 | 604 | 191 | 200 |
Inventor | V7MDI32-18WiFiR | 5.28 | 880 | 18,000 | 711 | 141 | 200 | 787 | 195 | 200 |
Inventor | V7MDI32-24WiFiR | 7.03 | 1,248 | 24,000 | 931 | 180 | 100 | 1,006 | 233 | 200 |
Inventor | V7MDI32-36WiFiR | 10.55 | 1,400 | 36,000 | 931 | 180 | 250 | 1,006 | 233 | 250 |
Inventor | V7MDI32-42WiFiR | 10.55 | 1,400 | 42,000 | 1,049 | 232 | 250 | 1,106 | 285 | 250 |
Inventor | V7MDI32-50WiFiR | 14.07 | 2,400 | 50,000 | 1,049 | 232 | 300 | 1,106 | 285 | 100 |
Inventor | V7MDI32-60WiFiR | 15.40 | 2,600 | 60,000 | 1,049 | 232 | 350 | 1,106 | 285 | 100 |
Midea | MTIU-12FNXD0 | 3.50 | 600 | 11,942 | 542 | 120 | 100 | 604 | 191 | 100 |
Midea | MTIU-18FNXD0 | 5.28 | 1,006 | 18,016 | 711 | 145 | 200 | 787 | 195 | 100 |
Midea | MTIU-24FNXD0 | 7.03 | 1,248 | 23,987 | 931 | 180 | 200 | 1,006 | 233 | 100 |
Midea | MTI-30FNXD0 | 8.70 | 1,400 | 29,685 | 1,191 | 180 | 250 | 1,266 | 233 | 100 |
Midea | MTI-36FNXD0 | 10.55 | 1,400 | 35,998 | 1,191 | 180 | 250 | 1,266 | 233 | 100 |
Midea | MTI-42FNXD0 | 12.30 | 1,871 | 41,969 | 1,049 | 232 | 300 | 1,106 | 285 | 100 |
Midea | MTI-48FNXD0 | 14.00 | 2,400 | 47,770 | 1,049 | 232 | 300 | 1,106 | 285 | 100 |
Midea | MTI-55FXND0 | 16.00 | 2,600 | 54,594 | 1,049 | 232 | 350 | 1,106 | 285 | 100 |
Toyotomi | DCT-A35IUINV | 3.50 | 750 | 11,942 | 590 | 127 | 100 | 705 | 205 | 100 |
Toyotomi | DCT-A53IUINV | 5.00 | 1,000 | 17,061 | 890 | 127 | 101 | 1,005 | 205 | 101 |
Toyotomi | DCT-A71IUINV | 7.00 | 1,400 | 23,885 | 1,190 | 147 | 102 | 1,305 | 225 | 102 |
Toyotomi | DCT-A90IUINV | 8.30 | 1,400 | 28,321 | 1,190 | 147 | 100 | 1,305 | 225 | 100 |
Toyotomi | DCT-A110IUINV | 10.00 | 2,100 | 34,121 | 751 | 200 | 101 | 965 | 269 | 101 |
Toyotomi | DCT-A125IUINV | 11.50 | 2,100 | 39,239 | 1,155 | 200 | 102 | 1,365 | 269 | 102 |
Panasonic | S-36PF1E5B | 3.60 | 840 | 12,284 | 597 | 191 | 100 | 805 | 260 | 100 |
Panasonic | S-45PF1E5B | 4.50 | 900 | 15,355 | 597 | 191 | 100 | 805 | 260 | 100 |
Panasonic | S-50PF1E5B | 5.00 | 960 | 17,061 | 597 | 191 | 100 | 805 | 260 | 100 |
Panasonic | S-60PF1E5B | 6.00 | 1,260 | 20,473 | 797 | 191 | 100 | 1,005 | 260 | 100 |
Panasonic | S-71PF1E5B | 7.10 | 1,260 | 24,226 | 797 | 191 | 100 | 1,005 | 260 | 100 |
Panasonic | S-100PF1E5B | 10.00 | 1,920 | 34,121 | 1,197 | 191 | 100 | 1,405 | 260 | 100 |
Panasonic | S-125PF1E5B | 12.50 | 2,040 | 42,651 | 1,197 | 191 | 100 | 1,405 | 260 | 100 |
Panasonic | S-140PF1E5B | 14.00 | 2,160 | 47,770 | 1,197 | 191 | 100 | 1,405 | 260 | 100 |
LG Air Conditioning | ARNU07GM1A4 | 2.20 | 540 | 7,507 | 862 | 205 | 100 | 854 | 236 | 100 |
LG Air Conditioning | ARNU09GM1A4 | 2.80 | 570 | 9,554 | 862 | 205 | 100 | 854 | 236 | 100 |
LG Air Conditioning | ARNU12GM1A4 | 3.60 | 660 | 12,284 | 862 | 205 | 100 | 854 | 236 | 100 |
LG Air Conditioning | ARNU15GM1A4 | 4.50 | 960 | 15,355 | 862 | 205 | 100 | 854 | 236 | 100 |
LG Air Conditioning | ARNU18GM1A4 | 5.60 | 1,020 | 19,108 | 862 | 205 | 100 | 854 | 236 | 100 |
LG Air Conditioning | ARNU24GM1A4 | 7.10 | 1,140 | 24,226 | 862 | 205 | 200 | 854 | 236 | 100 |
LG Air Conditioning | ARNU28GM2A4 | 8.20 | 1,680 | 27,979 | 1,211 | 202 | 100 | 1,210 | 235 | 100 |
LG Air Conditioning | ARNU36M2A4 | 10.60 | 1,920 | 36,168 | 1,211 | 202 | 100 | 1,210 | 235 | 100 |
LG Air Conditioning | ARNU42GM2A4 | 12.30 | 2,280 | 41,969 | 1,211 | 202 | 100 | 1,210 | 235 | 100 |
LG Air Conditioning | CL09F N50 | 3.20 | 690 | 10,919 | 865 | 154 | 100 | 905 | 160 | 100 |
LG Air Conditioning | CL12F N50 | 4.70 | 690 | 16,037 | 865 | 154 | 100 | 905 | 160 | 100 |
LG Air Conditioning | CL18F N60 | 5.80 | 900 | 19,790 | 1,065 | 154 | 100 | 1,105 | 160 | 100 |
LG Air Conditioning | CL24F N33 | 7.80 | 1,200 | 26,614 | 1,065 | 154 | 100 | 1,105 | 160 | 100 |
LG Air Conditioning | CM18FN10 | 5.60 | 990 | 19,108 | 862 | 275 | 100 | 855 | 236 | 100 |
LG Air Conditioning | CM24FN10 | 7.50 | 1,080 | 25,591 | 862 | 275 | 100 | 855 | 236 | 100 |
LG Air Conditioning | UM30FN10 | 8.30 | 1,320 | 28,321 | 862 | 275 | 100 | 855 | 236 | 100 |
LG Air Conditioning | UM36FN10 | 10.50 | 1,920 | 35,827 | 1,211 | 205 | 100 | 1,210 | 235 | 100 |
AUX Air Conditioner | AMSD-H07/4R3A | 2.20 | 600 | 7,507 | 575 | 116 | 100 | 689 | 173 | 100 |
AUX Air Conditioner | AMSD-H09/4R3A | 2.60 | 600 | 8,871 | 575 | 116 | 100 | 689 | 173 | 100 |
AUX Air Conditioner | AMSD-H12/4R3A | 3.60 | 680 | 12,284 | 575 | 116 | 100 | 689 | 173 | 100 |
AUX Air Conditioner | AMSD-H18/4R3A | 5.10 | 860 | 17,402 | 835 | 115 | 100 | 982 | 173 | 100 |
AUX Air Conditioner | ALMD-H18/NDR3HA | 5.00 | 1,150 | 17,061 | 816 | 180 | 100 | 1,044 | 209 | 100 |
AUX Air Conditioner | ALMD-H24/NDR3HA | 7.00 | 1,400 | 23,885 | 816 | 180 | 100 | 1,044 | 209 | 100 |
AUX Air Conditioner | ALMD-H36/NDR3HA | 10.55 | 1,900 | 35,998 | 1,218 | 183 | 150 | 1,280 | 183 | 150 |
AUX Air Conditioner | ALMD-H48/NDR3HA | 14.00 | 2,300 | 47,770 | 1,218 | 183 | 200 | 1,280 | 183 | 200 |
AUX Air Conditioner | ALMD-H60/NDR3HA | 16.00 | 2,300 | 54,594 | 1,218 | 183 | 250 | 1,280 | 183 | 250 |
Hisense | ADT-09UX4RRBL4 | 2.90 | 520 | 9,895 | 754 | 136 | 100 | 791 | 170 | 100 |
Hisense | ADT-12UX4RSBL4 | 3.52 | 600 | 12,011 | 754 | 136 | 100 | 791 | 170 | 100 |
Hisense | ADT-18UX4RSCL4 | 5.30 | 900 | 18,084 | 1,024 | 136 | 100 | 1,061 | 170 | 100 |
Hisense | AUD-24UX4RFCL4 | 7.20 | 1,100 | 24,567 | 1,024 | 136 | 100 | 1,061 | 170 | 100 |
Hisense | AUD-30UX4RFDH4 | 8.80 | 1,450 | 30,027 | 991 | 180 | 100 | 1,011 | 233 | 100 |
Hisense | AUD-36UX4RADH4 | 10.50 | 1,800 | 35,827 | 991 | 180 | 100 | 1,011 | 233 | 100 |
Hisense | AUD-42UX6RTHH4 | 12.50 | 1,750 | 42,651 | 1,210 | 227 | 100 | 1,240 | 313 | 100 |
Hisense | AUD-48UX6RPHH4 | 14.40 | 2,400 | 49,134 | 1,210 | 227 | 100 | 1,240 | 313 | 100 |
Hisense | AUD-60UX6RPHH4 | 17.50 | 2,400 | 59,712 | 1,210 | 227 | 100 | 1,240 | 313 | 100 |
Mitsubishi Electric | PEFY-P15VMS1-E | 1.70 | 420 | 5,801 | 665 | 155 | 100 | 705 | 162 | 100 |
Mitsubishi Electric | PEFY-P20VMS1-E | 2.20 | 480 | 7,507 | 665 | 155 | 100 | 705 | 162 | 100 |
Mitsubishi Electric | PEFY-P25VMS1-E | 2.80 | 540 | 9,554 | 665 | 155 | 100 | 705 | 162 | 100 |
Mitsubishi Electric | PEFY-P32VMS1-E | 3.60 | 600 | 12,284 | 665 | 155 | 100 | 705 | 162 | 100 |
Mitsubishi Electric | PEFY-P40VMS1-E | 4.50 | 660 | 15,355 | 865 | 155 | 150 | 905 | 162 | 100 |
Mitsubishi Electric | PEFY-P50VMS1-E | 5.60 | 780 | 19,108 | 865 | 155 | 150 | 905 | 162 | 100 |
Mitsubishi Electric | PEFY-P63VMS1-E | 7.10 | 990 | 24,226 | 1,065 | 155 | 200 | 1,105 | 162 | 100 |
Mitsubishi Electric | PEFY-P20VMA(L)-E | 2.20 | 510 | 7,507 | 665 | 183 | 100 | 705 | 229 | 100 |
Mitsubishi Electric | PEFY-P25VMA(L)-E | 2.80 | 510 | 9,554 | 665 | 183 | 100 | 705 | 229 | 100 |
Mitsubishi Electric | PEFY-P32VMA(L)-E | 3.60 | 630 | 12,284 | 665 | 183 | 100 | 705 | 229 | 100 |
Mitsubishi Electric | PEFY-P40VMA(L)-E | 4.50 | 840 | 15,355 | 865 | 183 | 100 | 905 | 229 | 100 |
Mitsubishi Electric | PEFY-P50VMA(L)-E | 5.60 | 1,020 | 19,108 | 865 | 183 | 100 | 905 | 229 | 100 |
Mitsubishi Electric | PEFY-P63VMA(L)-E | 7.10 | 1,140 | 24,226 | 1,065 | 183 | 100 | 1,105 | 229 | 100 |
Mitsubishi Electric | PEFY-P71VMA(L)-E | 8.00 | 1,260 | 27,297 | 1,065 | 183 | 100 | 1,105 | 229 | 100 |
Mitsubishi Electric | PEFY-P80VMA(L)-E | 9.00 | 1,260 | 30,709 | 1,065 | 183 | 100 | 1,105 | 229 | 100 |
Mitsubishi Electric | PEFY-P100VMA(L)-E | 11.20 | 1,980 | 38,216 | 1,365 | 183 | 100 | 1,405 | 229 | 100 |
Mitsubishi Electric | PEFY-P125VMA(L)-E | 14.00 | 2,400 | 47,770 | 1,365 | 183 | 100 | 1,405 | 229 | 100 |
Mitsubishi Electric | PEFY-P140VMA(L)-E | 16.00 | 2,520 | 54,594 | 1,565 | 183 | 100 | 1,605 | 229 | 100 |
Mitsubishi Heavy Industries | FDUM-40VF | 4.00 | 600 | 13,648 | 685 | 175 | 150 | 665 | 205 | 100 |
Mitsubishi Heavy Industries | FDUM-50VF | 5.00 | 600 | 17,061 | 685 | 175 | 150 | 665 | 205 | 100 |
Mitsubishi Heavy Industries | FDUM-60VF | 5.60 | 900 | 19,108 | 885 | 175 | 200 | 865 | 205 | 100 |
Mitsubishi Heavy Industries | FDUM-71VF1 | 7.10 | 1,140 | 24,226 | 885 | 175 | 200 | 865 | 205 | 100 |
Mitsubishi Heavy Industries | FDUM-100VF2 | 10.00 | 1,680 | 34,121 | 1,205 | 175 | 250 | 1,205 | 240 | 100 |
Mitsubishi Heavy Industries | FDUM-125VF2 | 12.50 | 1,920 | 42,651 | 1,205 | 175 | 300 | 1,205 | 240 | 100 |
Mitsubishi Heavy Industries | FDUM-140VF2 | 14.00 | 2,100 | 47,770 | 1,205 | 175 | 350 | 1,205 | 240 | 100 |
Mitsubishi Heavy Industries | SRR25ZM-S | 2.50 | 570 | 8,530 | 665 | 104 | 100 | 665 | 165 | 100 |
Mitsubishi Heavy Industries | SRR35ZM-S | 3.50 | 600 | 11,942 | 665 | 104 | 150 | 665 | 165 | 100 |
Mitsubishi Heavy Industries | SRR50ZM-S | 5.00 | 810 | 17,061 | 865 | 104 | 200 | 865 | 165 | 100 |
Mitsubishi Heavy Industries | SRR60ZM-S | 6.00 | 870 | 20,473 | 865 | 104 | 200 | 865 | 165 | 100 |
NOTES:
– Supply and Return dimensions are in mm.
